Technical Specification Sheet of CLW5041GSSAYF Water Sprinkler Truck
The pictures are for reference only. The actual product may vary
Main performance
| Vehicle parameters | ||||
|
1 |
Size Parameters |
External dimensions (mm) |
long | 5751 |
| wide | 1877 | |||
| high | 1990 | |||
| Overhang length (front overhang/rear overhang)(mm) | 977/1400 | |||
|
2 |
Mass Parameters |
Total mass (kg) | 4300 | |
| Curb weight (kg) | 2475 | |||
| Rated load capacity (kg) | 1500 | |||
| Chassis parameters | ||||
|
3 |
Chassis |
Chassis model | QL2040CTHWY | |
| Engine model/Power (KW) | 4KH1CT6S1/110 | |||
| Wheelbase (mm) | 3406 | |||
| Passenger count (including driver) | 5 | |||
| Maximum speed (km/h) | 140 | |||
| Tank capacity | ||||
|
4 |
Tank body |
Total tank capacity (L/Kg) | water | 1570 |
| External dimensions Length × Width × height (mm) | Water tank | 1550 * 1500 * 850 | ||
| Special Features | ||||
|
5 |
Sprinkler pump |
Model | 65QZ-40/50N | |
| Features | Self-priming centrifugal | |||
| Flow rate (m³/h) | 40 | |||
| Head (m) | 50 | |||
| Power | 10kw | |||
- Whole vehicle
- External dimensions: 5751mm× 1877mm × 1990mm
- Passenger capacity: 5
- Water tank: Total tank capacity 1570kg
- Pump: Flow rate 40m³/h
- Chassis
- Model: QL2040CTHWY
- Drive type: 4×4
- Wheelbase: 3406mm
- Engine:
Model: 4KH1CT6S1
Fuel type: Diesel
Rated output power: 110KW
Emission standard: National VI
- Transmission: Mechanical manual transmission, 5 forward gears
- Transfer case: Four-wheel drive mechanical manual, all-wheel drive/rear-wheel drive two-gear conversion
- Steering system: Left-hand drive, hydraulic power steering, adjustable steering wheel
- Braking system:
Brakes: Double tubing hydraulic brake front disc rear drum
Parking brake type: Manual
- Maximum speed: 140km/h
3.Driver’s cabin
1.Structure: Integral steel frame welded long head cab, fixed type.
2.Layout: Double row four doors, passenger capacity
- Upper Assembly
(1) Tank body
- Volume: 1570L(water)
- Structure: Square and round welded structure.
1 set of manhole and manhole cover, diameter φ 500mm.
The water injection pipe is located on the side of the tank, with a diameter of DN65.
- Material: Made of high-quality carbon steel welded together, the cylinder thickness is 3mm, the inner wall is fully treated for anti-corrosion, durable.
- Equipment: Manhole cover: Equipped with a quick locking and opening device, ensuring quick and safe opening.
Drain valve: Manually controlled
(2) Equipment box
- Structure: The box body is a square and round welded structure and is formed by integral rolling with the water tank at the front end.
- Material: Made of high-quality carbon steel.
- Warehouse door: Rear roller shutter door for easy opening.
5.Pump and waterway system
- Water pump: (Image for reference only)
Model: 65QZ-40/50N Self-priming Centrifugal
Flow rate: 40(m³/h)
Head (m):50
Power: 10kw
- Water cannon (optional):(Image for reference only) Installation location: Top of the equipment box
Range: approximately 25m
Rotation Angle: 360°
Pitch Angle; To 15 ° ~ 60 °
- Pipeline
Tank outlet pipe: DN50 with manual ball valve
External suction pipe: DN50
Gun outlet pipe: DN50, with manual ball valve (optional)
Hose outlet pipe: DN50 with manual ball valve
- Electrical system:
The rear is equipped with a combination of taillights and license plate lights that meet national standards.
Vi. Equipment configuration and arrangement
Equipping principles: Equipping according to the customer’s special requirements; When the customer does not have specific requirements, it shall be equipped in accordance with the company’s enterprise standards
- Whole vehicle painting
The exterior of the sprinkler truck is painted orange-red and can be customized according to customer requirements.
- Documents and materials attached to the vehicle
Chassis User Manual (1 copy)
Chassis Maintenance manual (1 copy)
Chassis Quality Warranty Card (1 copy
Chassis Qualification certificate (1 copy)
List of on-board maintenance tools (1 copy)
Pump operation and maintenance manual (1 copy)
Vehicle User Manual
Vehicle delivery list
Vehicle Certificate of Conformity
Vehicle handover checklist
Ix. Basic Equipment List with the Vehicle
| Serial Number | Name | Quantity | Serial Number | Name | Quantity |
| 1 | Water-absorbing rubber hose | One piece | 2 | Water tape 5m | 1 tray |
| 3 | Direct water gun | 1 | 4 | Ground fire hydrant wrench | 1 |
| 5 | Chassis specialized tools | 1 set |
